Take your time to read through the Garmin Edge 500 User Manual in order to understand the operating features and maintains the troubleshooting of the Garmin Edge 500 to get the most from your new Garmin Edge 500. This manual is organized into four section for your convenience. Always consult your physician before beginning or modifying any exercise program. See the Guide important safety information and product in the product box for product warnings and other important information. This product contains a lithium-ion battery. See the Guide important safety information and product in the product box for product warnings and other important information. The Edge is powered by a built-in lithium-ion battery that can be recharged with the AC charger or the USB cable included in the box of the product.To prevent corrosion, completely dry port mini-USB, the protective cover of the time and the area surrounding before charging or connecting to a computer. plug the AC charger into a standard wall outlet. lift the lid protector of the port mini USB. Connect the small end of the AC charger into the port, mini-USB. To connect the Edge to your computer using the USB cable, see page 8. Charge the Edge for at least three hours before using it. A fully charged battery can run up to 18 hours before recharging. For the best GPS reception, place the bike stand so that the front of the rim is pointing toward the sky. You can install bike stand on the stem (shown on page 3) or on the handlebar.
Garmin Edge 500 Specifications
| Physical size | (W × H × D) 1.9 × 2.7 × 0.85 in. (48.3 × 68.6 × 21.6 mm) |
| Weight | 2.0 oz. (56.7 g) |
| Display (W × H) | 1.25 × 1.5 in. (31.8 × 37 mm) |
| Resolution (W × H) | 128 × 160 pixels, with LED backlight |
| Water resistance | IPX7 |
| Data storage | Approximately 50 MB (at least 180 hours of ride data, typical use) |
| Computerinterface | USB |
| Battery type | 700 mAh rechargeable, built-in, lithium-ion battery |
| Battery life | 18 hours, typical usage |
| Operating temperature range | From 5°F to 140°F (from -15°C to 60°C) |
| Charging temperature range | From 32°F to 122°F (from 0°C to 50°C) |
| Radio frequency/protocol | 2.4 GHz wireless communications protocol |
| GPS receiver | High-sensitivity integrated GPS receiver |
| Altimeter | Internal barometric altimeter |
